FibroLAN Falcon-MX User Manual

Falcon M-Class | User Guide
68
4.7.3 VLAN Translation
This section allows you to perform:
VLAN Translation Port Configuration
VLAN Translation Mapping Table
4.7.3.1 VLAN Translation Port Configuration
This section allows you to configure switch Ports to use a given VLAN Translation Mapping Group.
This will enable all VLAN Translation mappings of that group (if any) on the selected switch port.
Figure 4-29: VLAN Translation Port Configuration
Table 4-27: Port to Group mapping Table Parameters
Port
The Port column shows the list of ports for which you can configure the VLAN
Translation Mapping Group.
Default
To set the switch port to use the default VLAN Translation Group click the
checkbox and press Save.
