Falcon M-Class | User Guide
239
4.17.6 CIST Port Configuration
The user is allowed to inspect the current STP CIST port configurations, and possibly change them
as well.
This section contains settings for physical and aggregated ports.
Figure 4-133: CIST Port Configuration displays
Table 4-127: CIST Port Configuration displays Parameters
CIST Aggregated and Normal Port Configurations
The switch port number of the logical STP port.
Controls whether STP is enabled on this switch port.
Controls the path cost incurred by the port
The Auto setting will set the path cost as appropriate by the physical link
speed, using the 802.1D recommended values.
Using the Specific setting, a user-defined value can be entered.
The path cost is used when establishing the active topology of the network.
Lower path cost ports are chosen as forwarding ports in favor of higher path
cost ports. Valid values are in the range 1 to 200000000.
Controls the port priority.
This can be used to control priority of ports having identical port cost. (See
above).
