4.5.1 Port State
This section provides an overview of the current switch port states
(Each M-Class series device has its own Port State display)
Figure 4-14: Port State
The port states are illustrated as follows:
RJ45
ports
SFP
ports
State
Disabled
Down
Link
Buttons
Refresh: Click to refresh the screen
Auto-refresh : Check this box to refresh the page
automatically. Automatic refresh occurs every 3 seconds
