Falcon M-Class | User Guide
249
4.18.2 IGMP Snooping VLAN Configuration
Navigating the IGMP Snooping VLAN Table
Each page shows up to 99 entries from the VLAN table, default being 20, selected through the
"entries per page" input field. When first visited, the web page will show the first 20 entries from
the beginning of the VLAN Table. The first displayed will be the one with the lowest VLAN ID found
in the VLAN Table.
The "VLAN" input fields allow the user to select the starting point in the VLAN Table. Clicking the
Refresh button will update the displayed table starting from that or the next closest VLAN Table
match.
The >> will use the last entry of the currently displayed entry as a basis for the next lookup. When
the end is reached the text "No more entries" is shown in the displayed table. Use the << button to
start over.
Figure 4-140: IGMP Snooping VLAN Configuration
Table 4-134: IGMP Snooping VLAN Configuration Parameters
Delete
Check to delete the entry. The designated entry will be deleted during
the next save.
VLAN ID
The VLAN ID of the entry.
Snooping
Enabled
Enable the per-VLAN IGMP Snooping. Up to 32 VLANs can be selected
for IGMP Snooping.
Querier Election
Enable to join IGMP Querier election in the VLAN. A router sends IGMP
Query messages onto a particular link. This router is called the Querier.
Querier election is used to dedicate the Querier, the only one router
sends Query messages, on a particular link. Querier election rule
defines that IGMP Querier or MLD Querier with the lowest IPv4/IPv6
address wins the election
IGMP Querier: A router sends IGMP Query messages onto a
particular link. This router is called the Querier. There will be only one
IGMP Querier that wins Querier election on a particular link.
MLD Querier :A router sends MLD Query messages onto a particular
link. This router is called the Querier. There will be only one MLD
Querier that wins Querier election on a particular link.
