Falcon M-Class | User Guide
117
Table 4-60: LCP2 Port Configuration parameters
The destination BPDU MAC addresses (01-80-C2-00-00-0X) and GARP (01-
80-C2-00-00-2X) MAC addresses for the settings contained in the same
row.
The L2CP mode for the specific port. The possible values are:
Peer: Redirect to CPU to allow 18 peering/tunneling/discard depending on
ECE and protocol configuration.
Forward: Allow to 20 peer/forward/tunnel/discard depending on ECE and
protocol configuration.
Discard: Drop frame.
Refresh : Click to refresh the page.
Save: Click to save changes.
Reset: Click to undo any changes made locally and revert to previously
saved values.
4.9.3 Bandwidth Profiles Configuration
This section displays current EVC ingress bandwidth profile configurations. These policers may be
used to limit the traffic received on UNI ports. A policer can limit the bandwidth of received
frames. It is located in front of the ingress queue. The settings can also be configured here
Figure 4-64: Bandwidth Profiles Configuration display
