4.5.4 SFP Monitoring
This section shows SFP digital diagnostic information
Figure 4-17: SFP Monitoring
Table 4-15: SFP Monitoring Parameters
RX Power
Module's receive optical power [dBm].
TX Power
Module's transmit optical power [dBm].
Temperature
Module's internal temperature.
Bias Current
Module's transmitter bias current [mA].
Supply voltage
Module's supply voltage [V].
Buttons
Refresh: Click to refresh the page immediately
Auto-refresh : Check this box to enable an automatic
refresh of the page at regular intervals
Note: Green indicator implies that the parameters are within the allowed range
