Falcon M-Class | User Guide
96
4.8.3 QoS Ingress Queue Policers
This section permits to configure the Queue Policer settings for all switch ports
A Policer can limit the bandwidth of received frames. It is located in front of the ingress queue.
Figure 4-49: QoS Ingress Queue Policers display
Table 4-47: QoS Ingress Queue Policers Config parameters
The port number for which the configuration below applies.
Enable or disable the queue policer for this switch port.
Controls the rate for the queue policer.
This value is restricted to 100-3276700 when "Unit" is kbps, and 1-3276
when "Unit" is Mbps
The rate is internally rounded up to the nearest value supported by the
queue policer.
Controls the unit of measure for the queue policer rate as kbps, or
Mbps
This field is only shown if at least one of the queue policers are
enabled.
Save:
Click to save changes.
Reset:
Click to undo any changes made locally and revert to previously saved
values.
