Remote Control
Conversion Table for the PM 5415/18 Command Set to 54200 Commands
6
6-53
Video Settings
Function Command for PM 5415/18 Command for 54200
Test Patterns:
- Digital Scan PAT DS PAT DIGI_ADC1
PAT DIGI_ADC2
PAT DIGI_Move
PAT DIGI_SCAN1_S
PAT DIGI_SCAN1_M
PAT DIGI_SCAN2_S
PAT DIGI_SCAN2_M
PAT DIGI_SCAN3_S
PAT DIGI_SCAN3_M
- Dots PAT DT PAT DOTS_W
PAT DOTS_B
- Greyscale PAT GS PAT Greyscale
- Crosshatch PAT HA PAT CH_WNN
PAT CH_WCN
PAT CH_WNT
PAT CH_WCT
PAT CH_BNN
PAT CH_BCN
PAT CH_BNT
PAT CH_BCT
- Multiburst PAT MB PAT Multiburst
- Black pattern (black screen) PAT OF PAT Off
- Purity
blue
cyan
green
magenta
black
red
white
yellow
PAT PB
PAT PC
PAT PG
PM
PAT PO
PAT PR
PAT PW
PAT PY
PAT PUR_BLUe
PAT PUR_Cyan
PAT PUR_Green
PAT PUR_Magenta
PAT PUR_BLAck
PAT PUR_Red
PAT PUR_White
PAT PUR_Yellow
- Special pattern 1 PAT S1 None
- Special pattern 2 PAT S2 None
- Special pattern 3 PAT S3 None
- Video cassette recorder test PAT VC PAT VCR_PAT1
PAT VCR_PAT2
PAT VCR_RES_Std
PAT VCR_RES_Hi
PAT VCR_Write
- White screen WH PAT WH_00
PAT WH_05
PAT WH_7_5
PAT WH_15/20 ... 95/100
