Function Command for PM 5415/18 Command for 54200
Test Patterns:
- Picture Line Up Generating
- Equipment (PLUGE)
None PLUGE
- Color temperature adjusting None PAT CTA_Small
PAT CTA_Medium
PAT CTA_Large
CTAB 0/50/100 (%)
CTAB 7.5/53.5/100 (IRE)
CTAC 0/5/15/20...95/100 (%)
CTAC 7.5/15/20...95/100 (IRE)
- Pattern of Insertion-Reference
Signal Line 17 (IRS17)
None PAT Irs 17
Insertion-Refernce Signal in line 17/330 None REFLIne ON/OFf
Aspect Ratio ASP WI
ASP NO
ASPR R16_9
ASPR R4_3
Chroma amplitude CHR OFF/ON CHRA 0/1/2...150
Video amplitude None VIDA 0/1/2...150
Video source VID INT
VID EXT
VIDSO Int
VIDSO Extern
VIDSO SCart
VIDSO BNc
VIDSO BMixed
VIDSO SMixed
Video polarity None VIDP Positive/Negative
SCART output None SCARTO Rgb/Y_C/CVBs/CV_Rgb
CVBS status None CVBS_stat Off/Auto
RGB sync None RGBSYnc Red/Green/Blue/Off
Sound Settings
Function Command for PM 5415/18 Command for 54200
Sound and vision carrier OSC ON/OFF None
Sound system None SNDSY AML
SNDSY FMMono
SNDSY FMGermany
SNDSY FMA1
SNDSY FMA2
SNDSY FMKorea
SNDSY Btsc
SNDSY NICAMB
SNDSY NICAMDK
SNDSY NICAMDC
SNDSY NICAMG
SNDSY NICAMI
SNDSY NICAML
