Printer Connection and Software Installation 79
USB Connection
A local printer is directly connected to your computer using the USB cable. If your printer is connected to a network
instead of your computer, skip this section and go to "Wired Network Connection" on page 79.
To connect the printer to a computer:
1 Connect the smaller USB connector into the USB port on the rear of the printer, and the other end of the cable
into a USB port of the computer.
NOTE:
• Ensure that you match the USB symbol on the cable to the USB symbol on the printer.
• Do not connect the printer USB cable to the USB port available on the keyboard.
Wired Network Connection
To connect the printer to a network:
1 Connect one end of the Ethernet cable into the Ethernet port on the rear of the printer, and the other end to a
LAN drop or hub.
To Next Page
