TX140 S1 Upgrade and Maintenance Manual 197
Hard disk drives / solid state drives
Figure 89: Removing the 3.5-inch HDD SAS / SATA backplane (B)
Ê Lift the 3.5-inch HDD SAS / SATA backplane up by about 1 cm to unhinge it
from the three hooks on the drive cage (see close-up).
