210 Upgrade and Maintenance Manual TX140 S1
System fan and air duct
Figure 98: Removing the system fan
Ê Carefully insert the fan module into the chassis as far as necessary to
connect the fan cable to the system board (1).
Ê Connect the fan cable to system board connector FAN1 SYS (2).
