516 Upgrade and Maintenance Manual TX140 S1
Cabling
Figure 348: Disconnecting the power cable from the 3.5-inch HDD SAS / SATA backplane
Ê Disconnect the power cable connector P6 from SAS / SATA backplane
connector X6.
Ê Remove the power cable from the chassis.
