c) If needed, touch the Approach Button to display the ‘Select Approach’ Screen with a
list of available approaches.
d) Scroll the list if needed and touch an Approach Selection Button to select the
approach and display the ‘Select Transition’ Screen.
e) Scroll the list if needed and touch a Transition Selection Button to select the transition
and return to the ‘Approach Selection’ Screen.
f) If a visual approach was selected, and it is necessary to change the Final Approach
Distance, touch the Final Approach Distance Button, then touch the numeric button
for the desired distance.
Or:
a) If the SBAS Button is available , touch the SBAS Button to display the keypad and
use it to select the SBAS channel number (The SBAS channel Button is only available
when an RNAV or GPS based approach is selected, or no approach is selected).
Or:
If the SBAS Button is not available , touch the Approach Button to display the ‘Select
Approach’ Screen. Scroll as needed and touch the Select by SBAS Channel Button
to display the keypad, and use it to select the SBAS channel number.
b) Touch the Enter Button to accept the SBAS channel and return to the ‘Approach
Selection’ Screen with the airport and approach selected.
c) Touch the Transition Button to display the ‘Select Transition’ Screen with a list of
available transitions.
d) Scroll the list if needed and touch a Transition Selection Button to select the transition
and return to the ‘Approach Selection’ Screen.
8) To set the landing runway, touch the Landing RWY Button to display the ‘Select Landing
Runway' Screen and touch the desired runway.
9) Touch the Preview Button, then the Show on Map Button to show the preview of
the approach on the active display pane or touch the Show Chart Button to show the
approach chart instead.
10) Touch the Load Button to insert the approach into the stored flight plan.
Activating a previously loaded approach:
1) From MFW Home, touch PROC.
2) Touch the Activate Approach Button to activate the approach.
Or:
1) From MFW Home, touch Flight Plan.
2) Touch the Approach Header Button to display the ‘Approach Options’ Window.
3) Touch the Activate Approach Button to activate the approach.
Activating a previously loaded approach with vectors to final:
1) From MFW Home, touch PROC.
