Runway Tab
Entering takeoff run available:
1) From MFW Home, touch PERF > Takeoff Data.
2) Touch the Runway Tab.
3) Touch the Runway Available Button to display the 'Takeoff Run Available' Screen.
4) Enter or change the takeoff run available distance:
a) Touch the Shorten DEP End Button to display the keypad.
b) Use the keypad to enter the reduction distance from the departure end of the runway.
c) Touch the Enter Button to accept the entry.
Or:
a) Touch the Takeoff Run Available Button to display the keypad.
b) Use the keypad to enter the takeoff run available distance.
c) If an Origin runway had been selected, touch the DEP Button or APPR Button to
shorten the distance from the approach or departure end.
d) Touch the Enter Button to accept the entry.
Or:
a) Touch the Shorten APPR End Button to display the keypad.
b) Use the keypad to enter the reduction distance from the approach end of the runway.
c) Touch the Enter Button to accept the entry.
5) Repeat Step 4 until the takeoff run data is displayed correctly.
6) Touch the Save Button to make the changes and return to the 'Takeoff Data' Screen.
Entering the takeoff Runway Required distance:
1) From MFW Home, touch PERF > Takeoff Data.
2) Touch the Runway Tab.
3) Touch the Runway Required Button to display the keypad.
4) Use the keypad to enter the takeoff runway distance required.
5) Touch the Enter Button to accept the entry, and return to the Runway Tab.
Manually entering takeoff runway elevation, heading, or gradient:
1) From MFW Home, touch PERF > Takeoff Data.
2) Touch the Runway Tab.
3) Touch the Runway Elevation Button, Runway Heading Button, or the Runway
Gradient Button to display the keypad.
4) Use the keypad to enter the value.
5) Touch the Enter Button to accept the entry, and return to the Runway Tab.
6) Repeat Steps 3 through 5 until all runway values are entered as desired.
