Reload runway data from database:
1) From MFW Home, touch PERF > Takeoff Data.
2) Touch the Runway Tab to display the runway data.
3) Touch the Reload from Database Button. The cyan pencil icon is removed from each
of the manual entries, and the values are replaced with data derived from the Navigation
Database.
Takeoff Config Tab
Selecting the flaps position on the 'Takeoff Data' Screen:
1) From MFW Home, touch PERF > Takeoff Data.
2) Touch the Takeoff Config Tab.
3) Touch the Flaps Button.
4) Touch the desired flap setting button and return to the Takeoff Config Tab.
Speed Bugs Tab
Enabling/disabling takeoff Vspeed bugs:
1) From MFW Home, touch PERF > Takeoff Data.
2) Touch the Speed Bugs Tab.
3) Enable/disable takeoff Vspeed bugs:
Touch the button for the desired Vspeed bug to enable or disable it. The annunciator bar
is green when enabled.
Or:
Touch the All On Button to enable all Vspeed bugs.
Or:
Touch the All Off Button to disable all Vspeed bugs.
Manually entering takeoff Vspeed values:
1) MFW Home, touch PERF > Takeoff Data.
2) Touch the Speed Bugs Tab.
3) Touch the desired Speed Button to display the keypad.
4) Use the keypad to enter the new speed value.
5) Touch the Enter Button to accept the entry and return to the 'Takeoff Data' Screen.
6) Repeat Steps 3 through 5 until all values are entered as desired.
Restoring all takeoff Vspeed values:
1) MFW Home, touch PERF > Takeoff Data.
2) Touch the Speed Bugs Tab.
3) Touch the Restore All Defaults Button. The system restores all default takeoff Vspeed
values and disables all takeoff Vspeed bugs.
