3) Scroll if necessary to view the WX Source Button. Cyan text on the button indicates
currently selected weather data link weather source.
4) Touch the WX Source Button.
5) Touch the button for the data link weather source to be used (such as SiriusXM, FIS-B,
or Connext, if installed).
Selecting a Data Link Weather Source for PFD Maps (Inset Map, HSI Map):
1) From PFW Home, touch the PFD Map Settings Button.
2) Scroll as needed and touch the WX Source Button. The button will change to reflect
desired source (SiriusXM, FIS-B, or Connext).
Or:
1) Press the PFD Map Settings Softkey.
2) Press the Data Link Settings Softkey.
3) Press the Data Link Softkey. Each selection of the softkey changes the source, which is
displayed in cyan on the softkey.
Setting up and customizing ‘Data Link’ Weather Products on navigation maps:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll through the list to view the available weather products.
4) Touch a weather product annunciator button to enable/disable the selected weather
product. Button annunciator is green when a weather product is enabled, or gray when
disabled.
5) If not selected, touch a range button next to the corresponding weather product, then
touch to select the maximum map range at which the system will display the selected
weather product.
Selecting Maximum Navigation Map Range for Data link Weather Products:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) If not selected, touch the Sensor Tab.
3) Scroll through the list to view the available weather products.
4) Touch a range button next to the corresponding weather product, then touch to select the
maximum navigation map range at which the system will display the selected weather
product.
Viewing legends for weather products enabled on the ‘Data Link’ (SiriusXM, Connext,
or FIS-B) Weather Pane:
1) From MFW Home, touch Weather > Weather Selection > ‘Data Link’ Weather >
‘Data Link’ Weather Settings
