2) Scroll as needed in the ‘Overlays’ Window and touch the Legend Button. The ‘Weather
Legends’ Window appears on the Touchscreen Controller.
3) Scroll as needed to view the weather legends in the ‘Weather Legends’ window.
4) To remove the ‘Weather Legends’ Window, touch Back or Home.
Selecting a map orientation for the Data Link (SiriusXM, Connext, or FIS-B) Weather
Pane:
1) From MFW Home, touch Weather > Weather Selection > ‘Data Link’ Weather >
‘Data Link’ Weather Settings.
2) Touch the Orientation Button to change the selected map orientation (displayed in
cyan).
3) Touch the desired map orientation button (Heading Up, Track Up, North Up, Sync to
Nav Map).
Displaying/Removing Weather Product Age Information on the (PFD Inset Map or HSI
Map):
1) From PFW Home, touch the PFD Map Settings Button.
2) Scroll as needed and touch the Weather Legend Button.
Or:
1) Press the PFD Map Settings Softkey.
2) Press the Weather Legend Softkey to enable/disable the weather product age
information.
Setting Data Link Radar Opacity on VFR/IFR Charts :
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the VFR Button > VFR Settings Button.
Or:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the IFR Low Button > IFR Low Settings Button.
Or:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the IFR High Button > IFR High Settings Button.
3) To increase or decrease the Data link Radar Opacity touch -/+ Button or move the slider
left or right to the desire setting. Setting the Data link Radar Opacity percentage to the
same percentage shown as the MFD Backlight Level will cause the Day/Night view to
switch at the current backlight setting. Adjusting the Data link Radar Opacity setting
greater than the MFD Backlight Level will cause the display to remain in Night Mode
longer. Adjusting the Data link Radar Opacity setting lower than the MFD Backlight
Level will cause the display to change to Day Mode sooner.
