Alert Type
PFD/’Map -
Terrain- SVT’
Page Alert
Touchscreen Controller
Pop-Up Alert
Voice Alert
Reduced Required Line
Clearance Caution (RLC)
TERRAIN CAUTION - WIRE
“Caution; Wire,
Wire”
Reduced Required
Obstacle Clearance
Caution (ROC)
TERRAIN CAUTION - OBSTACLE
“Caution; Ob-
stacle, Obstacle”
Imminent Obstacle
Impact Caution (IOI)
TERRAIN CAUTION - OBSTACLE
“Caution; Ob-
stacle, Obstacle”
Terrain SVT Alerts Summary
Alert Type
PFD/’Map
- TAWS-B’
Page Alert
Annunciation
Touchscreen Controller Pop-
Up Alert
Voice Alert
Excessive Descent
Rate Warning (EDR)
PULL UP PULL-UP
“Pull Up”
Reduced Required
Terrain Clearance
Warning (RTC)
PULL UP TERRAIN - PULL-UP
“Terrain, Terrain;
Pull Up, Pull Up”
Imminent Line Impact
Warning (ILI)
PULL UP
WIRE AHEAD - PULL-UP
“Wire Ahead; Pull
Up, Pull Up”
Reduced Required
Line Clearance
Warning (RLC)
PULL UP WARNING - WIRE
“Wire, Wire; Pull
Up, Pull Up”
Imminent Terrain
Impact Warning (ITI)
PULL UP TERRAIN AHEAD - PULL-UP
“Terrain Ahead,
Pull Up; Terrain
Ahead, Pull Up”
Reduced Required
Obstacle Clearance
Warning (ROC)
PULL UP OBSTACLE - PULL-UP
“Obstacle,
Obstacle; Pull Up,
Pull Up”
Imminent Obstacle
Impact Warning (IOI)
PULL UP OBSTACLE AHEAD - PULL-UP
“Obstacle Ahead,
Pull Up; Obstacle
Ahead, Pull Up”
Reduced Required
Terrain Clearance
Caution (RTC)
TERRAIN CAUTION - TERRAIN
“Caution, Terrain;
Caution, Terrain”
