Garmin CIRRUS PERSPECTIVE TOUCH+ - Page 231

Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin
190-02954-01 Rev. A 205
Annunciations & Alerts
Flight
Instruments EIS
Nav/Com/
XPDR/Audio
Flight
Management
Hazard
Avoidance AFCS
Additional
Features Annun/Alerts Appendix Index
Flight
Instruments EAS
Audio and
CNS
Flight
Management
Hazard
Avoidance AFCS
Additional
Features
Abnormal
Operation Annun/Alerts Appendix Index
Alert Type
PFD/’Map
- TAWS-B’
Page Alert
Annunciation
Touchscreen Controller Pop-
Up Alert
Voice Alert
Imminent Terrain
Impact Caution (ITI)
TERRAIN TERRAIN - AHEAD
“Terrain Ahead;
Terrain Ahead”
Required Reduced
Line Clearance Impact
Caution (RLC)
TERRAIN CAUTION - WIRE
“Caution, Wire;
Caution, Wire”
Imminent Line
Clearance Impact
Caution (ILI)
TERRAIN WIRE AHEAD
“Wire Ahead;
Wire Ahead”
Reduced Required
Obstacle Clearance
Caution (ROC)
TERRAIN CAUTION - OBSTACLE
“Caution,
Obstacle;
Caution,
Obstacle”
Imminent Obstacle
Impact Caution (IOI)
TERRAIN OBSTACLE AHEAD
“Obstacle Ahead;
Obstacle Ahead”
Premature Descent
Alert Caution (PDA)
TERRAIN TOO LOW - TERRAIN
“Too Low,
Terrain”
Touchdown Callout
(VCO) “500”
None None “Five-Hundred”
Excessive Descent
Rate Caution (EDR)
TERRAIN SINK RATE
“Sink Rate”
Negative Climb Rate
Caution (NCR)
TERRAIN DONT SINK
“Don’t Sink”
TAWS-B Alerts Summary
Alert Type
PFD/Terrain
SVT Display
Annunciation
Terrain SVT Display
Center Banner
Annunciation
Voice Alert
System Test in Progress.
TER TEST TERRAIN TEST
None
System Test Pass. None None
“Terrain System Test
OK”
Terrain Alerting Inhibited.
TER INH
None None
No GPS position.
TER N/A NO GPS POSITION
“Terrain System Not
Available”
