System Message Comments
DOC VIEWER MISMATCH
– See Document Viewer
Page for detailed info.
The documents on the database cards do not match. Ensure the aircraft
manufacturer installed documents on the bottom card of each display
match.
FAILED PATH – [xxxx]. A data path connected to the GDU or the GIA has failed.
FLIGHT PLAN CATALOG
– Last plan in catalog was
overwritten by an import.
Flight plan storage full. Last plan in the flight plan storage was overwritten
by an imported flight plan.
FPL TRUNC – Flight plan
has been truncated.
This occurs when a newly installed navigation database eliminates an
obsolete approach or arrival used by a stored flight plan. The obsolete
procedure is removed from the flight plan. Update flight plan with current
arrival or approach.
FPL WPT LOCK – Flight
plan waypoint is locked.
Upon power-on, The system detects that a stored flight plan waypoint
is locked. This occurs when an aviation database update eliminates an
obsolete waypoint. The flight plan cannot find the specified waypoint and
flags this message. This can also occur with user waypoints in flight plans
that are deleted. Remove the waypoint from the flight plan if it no longer
exists in any database, or update the waypoint name/identifier to reflect
the new information.
FPL WPT MOVE – Flight
plan waypoint moved.
The system has detected that a waypoint coordinate has changed due to
a new navigation database update. Verify that stored flight plans contain
correct waypoint locations.
FS 510 MANIFEST – FS
510 software mismatch.
Incorrect software version. The system should be serviced.
GDC1 MANIFEST –
GDC1 software mismatch,
communication halted.
The GDC1 has incorrect software installed. The system should be serviced.
GDC2 MANIFEST –
GDC2 software mismatch,
communication halted.
The GDC2 has incorrect software installed. The system should be serviced.
GDL69 CONFIG – GDL 69
config error. Config service
REQ’D.
GDL 69A SXM configuration settings do not match those of backup
configuration memory. The system should be serviced.
GDL69 FAIL – GDL 69 has
failed.
A failure has been detected in the 69A SXM. The receiver is unavailable.
The system should be serviced.
GDL69 MANIFEST –
GDL69 software mismatch,
communication halted.
The 69A SXM has incorrect software installed. The system should be
serviced.
