190-02954-01 Rev. A 229
Annunciations & Alerts
Flight
Instruments EIS
Nav/Com/
XPDR/Audio
Flight
Management
Hazard
Avoidance AFCS
Additional
Features Annun/Alerts Appendix Index
Flight
Instruments EAS
Audio and
CNS
Flight
Management
Hazard
Avoidance AFCS
Additional
Features
Abnormal
Operation Annun/Alerts Appendix Index
System Message Comments
GPS NAV LOST – Loss of
GPS navigation. Enable GPS
sensors.
Loss of GPS navigation due to GPS being disabled
GPS NAV LOST – Loss of
GPS navigation. GPS fail.
Loss of GPS navigation due to GPS failure.
GPS NAV LOST – Loss of
GPS navigation. Position
error.
Loss of GPS navigation due to position error.
GPS1 CHECK POSITION –
Position difference. Check
position sensors.
Check GPS1. From the ‘Sensors’ Screen on the Touchscreen Controller,
disable then enable GPS1 to clear the alert. If the alert persists, the system
should be serviced.
GPS2 CHECK POSITION –
Position difference. Check
position sensors.
Check GPS2. From the ‘Sensors’ Screen on the Touchscreen Controller,
disable then enable GPS2 to clear the alert. If the alert persists, the system
should be serviced.
GRS-GMU1 RS232
COMM FAIL – GMU
Software Loading
Inoperable
The RS-232 communication path between the GRS and GMU has failed.
The system should be serviced.
GRS-GMU2 RS232
COMM FAIL – GMU
Software Loading
Inoperable
The RS-232 communication path between the GRS and GMU has failed.
The system should be serviced.
GRS1 MANIFEST –
GRS1 software mismatch,
communication halted.
AHRS1 has incorrect software installed. The system should be serviced.
GRS2 MANIFEST –
GRS2 software mismatch,
communication halted.
AHRS2 has incorrect software installed. The system should be serviced.
GSR1 FAIL – GSR1 has
failed.
A failure has been detected in GSR1. The system should be serviced.
GTC1 CARD1 ERR – GTC1
card 1 is invalid.
The internal SD card in the Touchscreen Controller contains invalid data.
The system should be serviced.
GTC1 CARD1 REM –
GTC1 card 1 was removed.
Reinsert card.
The internal SD card in the Touchscreen Controller was removed. The
system should be serviced.
GTC1 CHK REQD: FAN
FAIL – Monitor GTC
Temperature
GTC1 fan failure. Monitor GTC temperature.
