System Message Comments
GTC1 CONFIG – GTC1
config error. Config service
REQ’D.
Touchscreen Controller configuration settings do not match those of
backup configuration memory. The system should be serviced.
GTC1 DB ERR – GTC1
[XXXX] database errors
exist.
The Touchscreen Controller detected a failure in one or more databases.
Ensure the data card is properly inserted. Replace data card. If problem
persists, the system should be serviced.
GTC1 INOP: OVERTEMP
– Temperature outside
operational range
GTC1 is outside of operational temperature range. The system should be
serviced.
GTC1 INOP: VOLTAGE –
Voltage outside standard
range
GTC1 is outside of operational temperature range. The system should be
serviced.
GTC1 MANIFEST –
GTC1 software mismatch,
communication halted.
The Touchscreen Controller has incorrect software installed. The system
should be serviced.
GTC1 MEM ERROR –
Internal Memory Error
The GTC is inoperative due to an internal memory fault. If problem
persists, remove and replace the GTC per Line Maintenance Manual
procedures. If problem has been resolved, return the aircraft to normal
operations.
GTC1 KEYSTK – GTC1
[key name] key is stuck.
A knob or key is stuck on the GTC bezel. Attempt to free the stuck control
by pushing or turning it several times. The system should be serviced if the
problem persists.
GTC1 OVERTEMP –
Reduced Backlight Level
Reduced backlight level.
GTC1 RESET – Corrective
Reset Performed
The GTC1 performed a corrective restart to repair an Single Event Upset.
There is no maintenance action required. The GTC1 is capable of resuming
normal operation after the corrective restart.
GTC2 CARD1 ERR – GTC2
card 1 is invalid.
The internal SD card in the Touchscreen Controller contains invalid data.
The system should be serviced.
GTC2 CARD1 REM –
GTC2 card 1 was removed.
Reinsert card.
The internal SD card in the Touchscreen Controller was removed. The
system should be serviced.
GTC2 CHK REQD: FAN
FAIL – Monitor GTC
Temperature
GTC1 fan failure. Monitor GTC temperature.
GTC2 CONFIG – GTC2
config error. Config service
REQ’D.
Touchscreen Controller configuration settings do not match those of
backup configuration memory. The system should be serviced.
