System Message Comments
GTX 3X5 1 ADS-B NO
POS – GTX not receiving
ADS-B position data
The transponder is not able to receive position information.
GTX 3X5 1 ADS-B NO TX
– Transponder: ADS-B out
has failed.
ADS-B is inoperative. The transponder may not be receiving a valid GPS
position. Other transponder functions may be available. Service when
possible.
GTX 3X5 1 ADS-B TRFC –
Datalink: Traffic failed.
The Transponder is incapable of processing traffic information.
GTX 3X5 1 ADS-B UAT
– Datalink: ADS-B in UAT
receiver has failed.
A failure has been detected in the UAT receiver.
GTX 3X5 1 CONFIG –
GTX config error. Config
service REQ’D.
The transponder configuration settings do not match those of backup
configuration memory. The system should be serviced.
GTX 3X5 1 FAIL – GTX is
inoperative.
There is no communication with the #1 transponder.
GTX 3X5 1 FIS-B WX –
Datalink: FIS-B Weather has
failed.
The transponder is unable to receive FIS-B weather information.
GTX 3X5 1 GND TEST –
<XPDR OR DLK 1>: Ground
test mode active.
Transponder / datalink ground test active.
GTX 3X5 1 OVER TEMP
– <XPDR OR DLK 1>: Over
temperature.
The system has detected an over temperature condition in GTX 1 / datalink
1. The transmitter operates at reduced power. If the problem persists, the
system should be serviced.
GTX 3X5 1 PRES ALT –
GTX not receiving ADS-B
press alt data
Unable to provide pressure altitude information.
GTX 3X5 1 SERVICE –
GTX needs service. Return
unit for repair.
GTX 1 should be serviced when possible.
GTX 3X5 1 TEST MODE
– Transponder: Test mode
active.
Transponder test mode active.
GTX 3X5 1 UNDER TEMP
– <XPDR OR DLK 1>:
Under temperature.
The system has detected an under temperature condition in GTX 1 /
datalink. The transmitter operates at reduced power. If the problem
persists, the system should be serviced.
