System Message Comments
HDG FAULT – AHRS1
magnetometer fault has
occurred.
A fault has occurred in the #1 GMU. Heading is flagged as invalid. The
AHRS uses GPS for backup mode operation. The system should be
serviced.
HDG FAULT – AHRS2
magnetometer fault has
occurred.
A fault has occurred in the #2 GMU. Heading is flagged as invalid. The
AHRS uses GPS for backup mode operation. The system should be
serviced.
HOLD EXPIRED – Holding
EFC time expired.
Expect Further Clearance (EFC) time has expired for the User Defined Hold.
INSIDE ARSPC – Inside
airspace.
The aircraft is inside the airspace.
LOI – GPS integrity lost.
Crosscheck with other
NAVS.
GPS integrity is insufficient for the current phase of flight.
LOSS OF GPS
NAVIGATION – Insufficient
Satellite Reception.
Loss of GPS navigation due to insufficient satellite reception.
LOW BANK ACTIVE –
Disengage for approach.
Low Bank mode is active. Disengage to continue approach.
LOW BANK ACTIVE –
Disengage for RNP less
than 1.0.
Low Bank mode active, disengage Low Bank Mode to continue the
approach.
LRG MAG VAR – Verify all
course angles.
The GDU internal model cannot ascertain the exact magnetic variance for
geographic locations near the magnetic poles. Displayed magnetic course
angles may differ from the actual magnetic heading by more than 2°.
LRU REPLACEMENT –
[LRU name].
The system has detected an LRU replacement. Perform LRU replacement
software or full configuration loading procedure.
MANIFEST – Software
mismatch, communication
halted.
The GSR1 has incorrect software installed. The system should be serviced.
MFD FAN FAIL – The
cooling fan for the PFD is
inoperative.
The cooing fan in the MFD has failed. The system should be serviced.
MFD1 CARD 1 ERR –
MFD1 card 1 is invalid.
The SD card in the top card slot of the MFD contains invalid data.
MFD1 CARD 1 REM –
MFD1 card 1 was removed.
Reinsert card.
The SD card was removed from the top card slot of the MFD. The SD card
needs to be reinserted.
