System Message Comments
MFD1 CARD 2 ERR –
MFD1 card 2 is invalid.
The SD card in the bottom card slot of the MFD contains invalid data.
MFD1 CARD 2 REM –
MFD1 card 2 was removed.
Reinsert card.
The SD card was removed from the bottom card slot of the MFD. The SD
card needs to be reinserted.
MFD1 CHK REQD: BTM
SD – Bottom SD card error.
The GDU bottom SD card is inoperative.
MFD1 CHK REQD: INT
SD – Internal SD card error.
The GDU internal SD card is inoperative.
MFD1 CHK REQD: TOP
SD – Top SD card error.
The GDU top SD card is inoperative.
MFD1 CMC INOP: Config
– CMC system inop due to
invalid config.
The CMC system logging capability is inoperative due to file invalid
configuration.
MFD1 CMC INOP:
Corrupt – CMC INOP due
to file system corruption.
The CMC system logging capability is inoperative due to file system
corruption.
MFD1 CMC INOP: MEM
Full – Internal SD card full.
The CMC system logging capability is inoperative due to insufficient
memory.
MFD1 CONFIG – MFD1
config error. Config service
REQ’D.
The MFD configuration settings do not match backup configuration
memory. The system should be serviced.
MFD1 DB ERR – MFD 1
[XXXX] database errors
exist.
The MFD detected database errors. Reload databases with new data card.
If problem persists, delete databases and reload with a new card.
MFD1 DB ERR – MFD1
obstacle database missing.
The obstacle database is present on another LRU, but is missing on the
specified LRU.
MFD1 DB ERR – MFD1
terrain database error exists.
The MFD detected a failure in the terrain database. Ensure that data card
is properly inserted. Replace data card. If problem persists, the system
should be serviced.
MFD1 HEAT TIME EXTD
– Heater taking extended
time to warm up.
The specified GDU heater is taking an extended time to warm up. The
system should be serviced.
MFD1 INOP: DISABLE
DSPL – Check Disable
Display Input Wiring
The specified GDU has insufficient voltage. The system should be serviced.
