Garmin CIRRUS PERSPECTIVE TOUCH+ - Page 261

Cockpit Reference Guide for the Cirrus SR2x with Perspective Touch+ by Garmin
190-02954-01 Rev. A 235
Annunciations & Alerts
Flight
Instruments EIS
Nav/Com/
XPDR/Audio
Flight
Management
Hazard
Avoidance AFCS
Additional
Features Annun/Alerts Appendix Index
Flight
Instruments EAS
Audio and
CNS
Flight
Management
Hazard
Avoidance AFCS
Additional
Features
Abnormal
Operation Annun/Alerts Appendix Index
System Message Comments
MFD1 INOP: LED FAULT
– Reduced backlight level:
needs repair.
The specified GDU has reduced backlight levels. The system should be
serviced.
MFD1 KEYSTK – MFD1
[key name] is stuck.
A key is stuck on the MFD bezel. Attempt to free the stuck key by pressing
it several times. The system should be serviced if the problem persists.
MFD1 MANIFEST – MFD1
software mismatch.
The MFD has incorrect software installed. The system should be serviced.
MFD1 MEM ERROR –
Internal Memory Error
The MFD is inoperative due to an internal memory error. If problem
persists, remove and replace the MFD per Line Maintenance Manual
procedures. If problem has been resolved, return the aircraft to normal
operations.
MFD1 OVER TEMP –
Check MFD1 temperature.
The specified GDU is over-temperature. The system should be serviced.
MFD1 RESET – Corrective
Reset Performed
The GDU performed a corrective restart to repair a Single Event Upset.
There is no maintenance action required. The GDU is capable of resuming
normal operation after the corrective restart.
MFD1 SERVICE – MFD1
needs service. Return unit
for repair.
The MFD self-test has detected a problem. The system should be serviced.
MFD1 TERRAIN DSP –
MFD1 Terrain awareness
display unavailable.
One of the terrain or obstacle databases required for TAWS in the MFD is
missing or invalid.
MODEL MISMATCH –
Model mismatch for GDU or
GTC. Service required.
The GTC or GDU modes are not compatible. The system should be
serviced.
NAV #1 INOP: CAL –
Factory NAV Calibration
Lost or Corrupted.
NAV 1 calibration version error. Check COM calibration.
NAV #1 INOP: CONFIG
– Check NAV Software and
Config.
There is a problem with the NAV 1 software configuration. Check the
configuration. If the problem persists, the system should be serviced.
NAV #1 INOP: INTRL –
NAV Internal Fault.
NAV 1 has an internal fault.
NAV #1 INOP: SERL
– Internal NAV Serial
Communication Fault.
NAV 1 serial communication fault. Check NAV serial communication.
NAV #1 INOP: SYNTH –
NAV Synthesizer Lock Fault.
NAV 1 has a synthesizer lock fault.
