Level 1 Level 2 Level 3 Level 4
Description
SVT Mode Displays the Synthetic Vision Technology
(SVT) settings softkeys.
Auto Selects SVT Auto Mode. The softkey
annunciator is green when the function is on.
Flight Selects SVT Flight Mode. The softkey
annunciator is green when the function is on.
Off SVT mode off. The softkey annunciator is
green when the function is off.
SVT
Settings
Displays SVT Settings softkeys.
Pathways Displays Pathway boxes on the synthetic
vision display.
Runway
Locator
Displays cyan chevrons and cyan mile
markers which extend 10 nm from the
programmed runway.
Airport
Signs
Displays position markers for airports within
approximately 15 nm of the current aircraft
position. Airport identifiers are included
when the airport is within approximately 9
nm.
Wire
Displays power lines on the synthetic vision
display.
Attitude
Instruments
Displays the softkeys for enabling or
disabling Synthetic Vision Technology (SVT)
features.
Horizon
Heading
Displays compass heading along the Zero-
Pitch Line.
PFD Mode Enables or disables a Display Pane to the
right or left (depending on pilot-side or
copilot-side) on the PFD / PFW:
FULL: Display Pane is disabled. The PFD /
PFW display occupies the full screen.
Split: Display Pane is enabled. The PFD /
PFW screen is split between the PFD / PFW
display and the Display Pane.
