Level 1 Level 2 Level 3 Level 4
Description
Bearing 1 Cycles the Bearing 1 Information Window
through NAV1, NAV2, GPS, ADF1, and Off.
Bearing 2 Cycles the Bearing 2 Information Window
through NAV1, NAV2, GPS, ADF1, and Off.
Other PFD
Settings
Displays additional PFD / PFW settings
softkeys.
Wind Displays the wind option softkeys.
→DEG KT Total wind direction arrow with digital
numeric direction and speed.
↑→KT Headwind/tailwind and crosswind arrows
with numeric speed components.
Off Wind information not displayed.
AOA Selects the display mode for the Angle of
Attack (AOA) Indicator on the PFD / PFW:
Auto: Selects AOA ‘Auto’ mode. (See Flight
Instruments section)
On: Displays AOA Indicator on the PFD /
PFW.
Off: Removes AOA Indicator from the PFD
/ PFW.
Altitude
Units
Displays softkeys to select altitude unit
parameters.
Meters Displays altimeter meters overlay.
IN Displays the BARO setting as inches of
mercury.
HPA Displays the BARO setting as hectopascals.
OBS Selects OBS mode on the CDI when
navigating by GPS (only available with
active leg). When OBS is on, the softkey
annunciator is green. ‘SUSP’ will replace
‘OBS’ when waypoint sequencing is
suspended.
Active
NAV
Cycles through GPS, NAV1, and NAV2
navigation modes on the CDI.
Sensors Displays the sensor selection softkeys.
