9) Touch a Waypoint Selection Button to display the waypoint information on the
Touchscreen Controller.
10) Touch the Waypoint Options Button, then the Show on Map Button to display the
Intersection, VRP, VOR, NDB, or User WPT Information Pane, if needed.
Viewing information for nearest Intersection, VRP, VOR, NDB, or User Waypoint:
1) From MFW Home, touch Nearest > INT, VRP, VOR, NDB, or User.
2) Touch a Nearest Waypoint Button to display the 'Waypoint Options' Window.
3) Touch the Show on Map Button to display the Nearest Intersection/VRP/VOR/NDB/User
pane, if needed.
4) Touch the Intersection, VRP, VOR, NDB, or User Waypoint Info Button to display the
selected waypoint's information screen.
Creating user waypoints from the 'Create User Waypoint' Screen:
1) From MFW Home, touch Waypoint Info.
2) Access the 'Create User Waypoint' Screen:
Touch the Create Waypoint Button.
Or:
a) Touch the User Waypoint Button.
b) Touch the WPT List Tab.
c) Touch the Add User Waypoint Button.
3) Touch the User Waypoint Name Button to display the keypad.
4) Use the keypad and the Enter Button to select a User Waypoint Name.
5) If desired, touch the Type Button to open the 'Select User Waypoint Type' Screen to
change the setting from Route to Airport.
a) Touch the Airport Button.
b) Touch the Elevation Button.
c) Use the keypad and the Enter Button to select the airport elevation.
6) If desired, define the location parameters of the waypoint in one of the following ways:
a) Touch the Mode Button to display the 'Select User Waypoint Mode' Screen.
b) Touch the RAD/DIS Button to select the bearing/distance from a waypoint.
c) Touch the REF Button to display the keypad.
d) Use the keypad and the Enter Button, or the Find function, to select the reference
waypoint.
e) Touch the RAD Button to display the keypad.
f) Use the keypad and the Enter Button to select the radial.
g) Touch the DIS Button to display the keypad.
