h) Use the keypad and the Enter Button to select the distance.
Or:
a) Touch the Mode Button to display the 'Select User Waypoint Mode' Screen.
b) Touch the RAD/RAD Button to select the bearings from two waypoints.
c) Touch the REF1 Button to display the keypad.
d) Use the keypad and the Enter Button, or the Find function, to select the waypoint.
e) Touch the RAD1 Button to display the keypad.
f) Use the keypad and the Enter Button to select the radial.
g) Repeat the previous steps for the second reference waypoint (REF2 Button) and
radial (RAD2 Button).
Or:
a) Touch the Mode Button to display the 'Select User Waypoint Mode' Screen.
b) Touch the LAT/LON Button to select the latitude/longitude mode.
c) Touch the LAT/LON Button to display the keypad.
d) Use the keypad and the Enter Button to select the latitude and longitude.
Or:
a) Touch the Mode Button to display the 'Select User Waypoint Mode' Screen.
b) Touch the P. POS Button to select the present position type as defined by latitude/
longitude values.
7) If desired, change the waypoint comment:
a) Touch the Comment Button to display the keypad.
b) Use the keypad and the Enter Button to select the comment.
8) If desired, touch the Temporary Button to change the waypoint storage method. When
the annunciator on the button is green, the waypoint is only stored until the next power
cycle. When the annunciator is gray, the waypoint is stored until manually erased.
9) Touch the Create Button to accept the new user waypoint. If RAD/RAD was used to
define the waypoint, and the radials do not intersect, a message "The radials entered
do not intersect" will be displayed. Touch the OK Button to return to the 'Create User
Waypoint' Screen.
Creating user waypoints from map displays:
1) Push the lower knob to activate the panning function and display the 'Map Pointer
Control' Screen on the Touchscreen Controller.
2) Use the Touchpad to pan to the map location of the desired user waypoint.
3) Touch the Create WPT Button. The 'Create User Waypoint' Screen is displayed with the
captured position.
4) Touch the User Waypoint Name Button to display the keypad.
