8) Touch the OK Button in response to the question "Are you sure you want to modify this
waypoint?".
9) If the user waypoint is part of an existing flight plan, a second pop up window is
displayed. Touch the OK Button in response to the question "User waypoint is part of at
least one flight plan. Any modifications affect the associated flight plan(s)."
Editing a user waypoint type, mode, elevation, and location:
1) From MFW Home, touch Waypoint Info > User Waypoint.
2) If needed, touch the WPT List Tab to display the list of user waypoints, and touch the
desired User Waypoint Selection Button.
3) Touch the Waypoint Options Button to display the 'Waypoint Options' Window.
4) Touch the Edit Button to display the 'Edit User Waypoint' Screen.
5) To edit the type of User Waypoint:
a) Touch the Type Button to display the 'User Waypoint Type' Window.
b) Touch the Route Button to select the type and return to the previous screen.
Or:
a) Touch the Type Button to display the 'User Waypoint Type' Window.
b) Touch the Airport Button to select the type and return to the previous screen.
c) Touch the Elevation Button.
d) Use the keypad and the Enter Button to select the airport elevation and return to the
previous screen.
6) To edit the mode of User Waypoint:
a) Touch the Mode Button to display the 'Select User Waypoint Mode' Window.
b) Touch the RAD/DIS Button, the RAD/RAD Button, the LAT/LON Button, or the P.
POS Button to select the mode and return to the previous screen.
7) If the P. POS Mode is selected, skip to step 8. Otherwise, perform the following to edit
the location parameters of the waypoint:
a) Touch the REF Button, the RAD Button, the DIS Button, or the LAT/LON Button to
bring up the keypad.
b) Use the keypad and the Enter Button to select the user waypoint location.
c) Repeat as necessary until the location changes are complete (Reference Waypoint,
Radial, Distance, or Latitude and Longitude).
8) Touch the Save Button to accept the changes.
9) Touch the OK Button in response to the question “Are you sure you want to modify this
waypoint?”.
10) If the user waypoint is part of an existing flight plan, a second pop up window is
displayed. Touch the OK Button in response to the question "User waypoint is part of at
least one flight plan. Any modifications affect the associated flight plan(s)."
