3) Touch the Edit Heading Leg Button to display the keypad.
4) Use the keypad to enter the heading and touch Enter.
Removing a heading from the active flight plan:
1) From MFW Home, touch the Flight Plan Button.
2) Scroll the list if necessary and touch the desired 'manseq' heading Waypoint Selection
Button to display the 'Waypoint Options' Window.
3) Touch the Remove WPT(s) Button.
4) Touch the OK Button in response to 'Remove <waypoint name>?'. The heading is
removed. To cancel the request, touch the Cancel Button.
Creating a fix:
1) From MFW Home:
Touch Flight Plan > Flight Plan Options > Fix Function.
Or:
a) Touch the Flight Plan Button.
b) Touch any Waypoint Selection Button to open the 'Waypoint Options' Window.
c) Touch the Fix Function Button.
2) Touch the Type Button to open the 'Select Fix Type' Screen.
3) Touch the button corresponding to the desired type of fix.
4) For an Abeam fix:
a) Touch the Reference Button.
b) Enter the waypoint identifier, and touch the Enter Button. The 'Radial' Field will
auto-populate.
Or:
For a Radial fix:
a) Touch the Reference Button, enter the waypoint identifier, and touch the Enter
Button.
b) Touch the Radial Button, enter the radial value, and touch the Enter Button.
Or:
For a Distance fix:
a) Touch the Reference Button, enter the waypoint identifier, and touch the Enter
Button.
b) Touch the Distance Button, enter the distance value, and touch the Enter Button.
Or:
For a LAT/LON fix, touch the LAT/LON Button, to open the 'LAT/LON' Screen:
For a latitude intersecting fix, enter the latitude, and touch the Enter Button.
Or:
