Activating a vertical navigation direct-to for an existing altitude constraint:
1) From MFW Home, touch Flight Plan.
2) Scroll the active flight plan list and touch the desired VNAV ALT Button.
3) Touch the VNAV ¯ <waypoint> Button to activate the vertical navigation direct-to.
Vertical guidance begins to the altitude constraint for the selected waypoint.
Or:
1) From MFW Home, touch Flight Plan > VNAV.
2) If necessary, touch the Profile Tab. Touch the VNAV ¯ Button to display the 'Select
VNAV Direct To' Screen with a list of possible VNAV direct-to choices.
3) Scroll the list, if necessary, and touch a VNAV Waypoint Selection Button.
4) Touch the OK Button to activate the vertical navigation direct-to. Vertical guidance
begins to the altitude constraint for the selected waypoint.
5) Touch the Back Button to exit and return to the previous screen.
Removing an altitude constraint when vertical navigation direct-to is active:
1) From MFW Home, touch Flight Plan.
2) Scroll the active flight plan list and touch the VNAV ALT Button for the waypoint receiving
VNAV direct-to guidance.
3) Touch the Remove Constraint Button.
4) Touch the OK Button in response to the question “Remove Altitude Constraint?”.
Vertical navigation direct-to guidance for the altitude constraint is canceled, and the
altitude constraint is removed from the flight plan.
VNAV Enablement
Enabling/disabling VNAV guidance:
1) From MFW Home, touch Flight Plan > VNAV.
2) If necessary, touch the Settings Tab. Touch the VNAV Enabled Button to enable/disable
vertical navigation.
Active Flight Plan VNAV Profile
Entering or modifying a flight path angle constraint in the active flight plan:
1) From MFW Home, touch Flight Plan > VNAV.
2) Touch the Profile Tab, if needed. Then touch the FPA Button to display the 'VNAV Flight
Path Angle' Screen.
3) Use the keypad to select the angle. (FPA must be between -7.0 and -1.00)
4) Touch the Enter Button to accept the new FPA constraint.
Removing a flight path angle constraint in the active flight plan:
1) From MFW Home, touch Flight Plan > VNAV.
