2) Touch the Profile Tab, if needed. Then touch the FPA Button to display the 'VNAV Flight
Path Angle' Screen.
3) Touch the Remove FPA Button.
4) Touch the OK Button. The FPA reverts to the FMS computed value, or to dashes. To
cancel the request, touch the Cancel Button.
Changing the flight plan descent FPA default:
1) From MFW Home, touch Flight Plan > VNAV.
2) Touch the Descent Tab.
3) Touch the Default Flight Path Angle Button to bring up the selection window.
4) To define a new descent FPA, touch the Pilot-Defined Descent Button. Then, use the
keypad and the Enter Button to enter the FPA and return to the previous screen.
Or:
To use a pre-defined FPA, touch the desired descent button to select it and return to the
previous screen.
Entering or modifying the VS Target in the active flight plan:
1) From MFW Home, touch Flight Plan > VNAV.
2) Touch the VS Target Button to display the 'VNAV VS Target' Screen.
3) Use the keypad to select the descent rate.
4) Touch the Enter Button to select the new vertical speed target and to display a new
system-calculated FPA.
Vertical Situation Display
Enabling/disabling the VSD:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Inset Window Tab.
3) Touch the VERT Situation Display Button to enable/disable display of the VSD.
Changing the VSD Mode:
1) From MFW Home, touch Map > Map Selection > Map Settings.
2) Touch the Inset Window Tab.
3) Touch the VERT Situation Display Settings Button.
4) Touch the Mode Button to display the 'Mode Selection' Window.
5) Touch a Mode Selection Button to select it and return to the 'Vertical Situation Display
Settings' Window.
Advisory Descent
Enabling/disabling the Advisory Descent:
1) From MFW Home, touch Flight Plan > VNAV.
