Brivo OEC 715/785/865 Mobile C-Arm X-Ray Product Service Manual
3-2
3.1. Overview
This chapter describes the installation procedure of Brivo OEC 715/785/865 Mobile C-Arm X-ray Product.
3.2. Pre-Installation
3.2.1. Dimensions and Weights of System
Dimensions:
C-Arm: Hmax/Hmin
×
W
×
L=215/170.5cm
×
78cm
×
179cm (84.6’’/67.1”
×
30.7’’
×
70.3’’)
Workstation: H
×
W
×
L=167cm ×64cm×90cm (65.7’’ ×25’’×35.4’’)
Weights:
C-Arm: 260±10kg
Workstation: 170±10kg
3.2.2. Site Requirement
Scan room (H× W ×L) ≥2.8 m× 5.5 m ×5.0 m
Entrance (H×W) ≥2.0 m ×1.2 m
Aisle (W) ≥2m
Enough room should be provided for the movement, installation and operation of the
system.
The floor should be hard enough to support the system. It should also be smooth and
horizontal.
WARNING
WARNING
