Brivo OEC 715/785/865 Mobile C-Arm X-Ray Product Service Manual
3-6
3.3.2. Unpack C-Arm
1. Place the C-Arm and workstation packages on the flat and leave enough space around.
2. Cut off the binding tie and remove the cardboard coping and box of the C-Arm. Then remove the
seal wrapper of the C-Arm.
3. Remove the limitation frame of Image intensifier and Monoblock.
4. Lock the cross-arm, Wigwag, lateral rotation and orbital movement brakes. Get the accessory
packages, wood crowbar and ramp from the C-Arm package. Put the wood ramp behind of the
C-Arm.
The ramp and crowbar will also be used to workstation unpacking.
5. Remove four metal bracket fixed screws as below.
