Brivo OEC 715/785/865 Mobile C-Arm X-Ray Product Service Manual
4-2
4.1. Overview
The Calibration described herein should be performed each time you replace a major system
component. Perform these tests in sequence that appears in this section if necessary.
The following tools and test equipment are required to complete the calibration.
Standard Tool and Equipment
Item
Tool and Equipment
1
Oscilloscope Tektronix 2236 or equivalent
2
Multimeter or equivalent
3
Spatial Resolution Tool
4
Lead Apron
5
kV meter
6
Dosimeter
7
Ampere meter or equivalent
8
Ruler longer than 12 inches (30cm)
9
Erasable marker (whiteboard marker)
10
mAs meter
11
Precision flat head screwdriver (∅3mm or less) to adjust camera iris, focus
12
Transparent adhesive tape, with cutter (or need scissor or knife to cut the tape)
13
10’’
×
12’’ Film
Special Tool
Item
Tool
GE part number
1
Three copper sheets, each 1mm thick
00-877682-01
2
9-inch BAFT Tool or UBAT (Universal Beam
Alignment Template)
00-878105-02 or 5307604
3
PWA, extend board
5085609
The system will produce X-Rays when implementing the following procedures. Take
appropriate measures and precautions to protect yourself and others from X-Ray
exposure.
Must obey the following steps to guarantee the safe operation of the C-Arm. Improper
adjustment may cause premature failure of major system components.
If the generator has not been powered for more than 3 months, perform the generator
warm-up procedure in section 4.5.
Provide appropriate X-ray protection on surface of Image Intensifier in Image Intensifier
non-ralated calibration and verification to protect Image Intensifier.
WARNING
CAUTION
