GE Brivo OEC 715 - Circuit Breaker; Earth Leakage Current

Technical Reference
9-3
• 28A (200V)
• 25A (220V/230V/240V)
Rated Continuous Line Current:
• 20A (100V/110V/120V)
• 12A (200V)
• 10A (220V/230V/240V)
Maximum line impedance: 0.3
Ω
|0.6
Ω
|0.6
Ω
Max Line Regulation (Percent): 15% at maximum radiographic exposure.
Line regulation is based on measurements made at the input (primary winding) of the isolation
transformer under standby conditions and at maximum radiographic exposure by the following
equation:
Line regulation = 100 (Vn - V1)/V1
Where Vn = no load voltage (standby), and V1 = loaded voltage (maximum radiographic exposure).
16A power supply is required in China. And 20 A is required in Japan.
9.2.4. Circuit Breaker
Breaker for 110V:
• Rated Voltage AC 250 V
• Frequency 50 Hz /60 Hz
• Rated Current 20A (AC)
Breaker for 220V:
• Rated Voltage AC 250 V
• Frequency 50 Hz /60 Hz
• Rated Current 12A (AC)
9.2.5. Earth leakage current
Normal condition 0.5mA
Single fault condition 0.5mA
