Brivo OEC 715/785/865 Mobile C-Arm X-Ray Product Service Manual
3-4
3.2.5. Tools and Test Equipment
Standard Tools and Test Equipment are required to install the system. In addition to standard service
tools and test equipment, the following special tools and standard test equipment are required to
complete this procedure.
Tool and Equipment List
Item
Standard Tool and Equipment
Comments
1
Screw Drivers
Recommend use auto screw
driver with Philips 2 head.
2
Wrench
Monkey wrench or wrench for
M8 and M12 hexagon screw
3
Allen Keys
4
Dosimeter
5
10’’
×
12’’ Film
6
Blank CD/DVD disk
7
Spatial Resolution Tool
8
Lead Apron, thicker than 3mm
9
Pinchers
10
Scissors
11
Stopwatch
12
Network cable
13
Printer paper or film
14
Ruler longer than 12 inches (30cm)
15
Digital volt-ohm meter or equivalent
Item
Special Tool
GE part number
1
9 inch Film cassette holder (if required)
5085005
2
3 copper sheets, each 1mm thick
00-877682-01
3
9" BEAM ALIGHMENT TOOL ASSEMBLY or
UBAT(Universal Beam Alignment Template)
00-878105-02
5307604
4
Service Tool External DVD Surgery (If customer
order the Wireless DICOM Kit)
5075511
