GE Brivo OEC 715 Service Manual

Replacement
7-15
7.3.3. Calibration Tool Matrix
Standard tools are not included in matrix below, for example: screw driver, TORX screw driver, Allen key metric and inch (For Brivo OEC 865
Camera Iris and Focus calibration).
PN
Description
X-ray Generator Warm
mA Calibration
mA Pre Heat table Cali.
mAs Calibration
KV Calibration
Camera Centering
Collimator Centering
Collimator Calibration
I.I. Field Size Check
Limiting Field Size Check
ABS Tracking Check&Cal.
Shading Calibration
Image Resolution check
DAP Accuracy Ver. and Cal.
Reinstall OS and APP SW
Monitor
Brightness and
contrast
adjust if needed
Laser aimer Calibration
Power Tolerance Check
Standard Tool
Dose Meter
√
√
Standard Tool
Oscilloscope Tektronix 2236 or equivalent
√
√
√
Standard Tool
Multimeter or equivalent
√
√
√
Standard Tool
Spatial Resolution Tool
√
Standard Tool
kV meter
√
Standard Tool
Ampere meter or equivalent
√
√
Standard Tool
Ruler longer than 12 inches (30cm)
√
Standard Tool
Erasable marker (If needed)
√
√
Standard Tool
mAs meter
√
00-877682-01
Three copper sheets, each 1mm thick
√
00-878105-02
9” BAFT (BEAM ALIGHMENT TOOL ASSEMBLY)
√
√
√
√
√
5307604
UBAT (Universal Beam Alignment Template)
√
√
√
√
√
5085609
PWA, Extend Board
√
√
√
5085005
Asm, 9 Inch Cassette Holder (if required)
√
N/A
Film
√
5075511
Workstation Software Installation DVD-RW
√
