System Overview
2-31
D36 flickers when MCU work well
SPI_SOMI. D37 flickers on MCB
FRAME_SYNCH. D38 is flickering on MCB when FRAME_SYNCH is available
FOOT_BUTTON2 & FOOT_COM. D39 turns off when press
D40 turns off when FPGA configuration completes
D41 turns off when footswitch interupt signal is available to MCU
D42 turns off when FPGA configuration completes
EMERGENCY_SWT & REF_EMERGENCY_SWT. D43 turns off when press
DB_INT. D44 lights on MCB when pressing button of control panel
WK_Y & WK_Z. D45 on MCB lights normally, and flickers in communication
D46 lights when EXPOSURE command is sent out
HAND_FLU_SECURITY & HAND_COM & FOOT_FLU_SECURITY & FOOT_COM. D47
lights when either HAND_FLU_SECURITY & HAND_COM or FOOT_FLU_SECURITY
& FOOT_COM connected
PROTECT_A. D48 lights when one of two removeable filters is removed
HAND_FLU & HAND_COM. D52 turns on when press
PROTECT_A. D53 lights when the other of two removeable filters is removed
Light lights when +3.3V is available
Light lights when +15V from PS1 is available
Light lights when +5V from PS1 is available
Light lights when -15V from PS1 is available
Light lights when +24V from PS2 is available
Light lights when +24V from PS1 is available
FOOT_FLU & FOOT_COM. D69 turns off when press
Light lights when +12V from PS2 is available
POT
