GE P742

P74
x/EN IT/Na7
Introduction
(IT) 1
-10
MiCOM P741, P742, P743
IT
Information Required with Order
Variants
P743 Busbar Protection Peripheral Unit (60TE) P743
Vx Aux Rating
24 - 54Vdc 7
48 - 125Vdc (40 - 100Vac) 8
110 - 250Vdc (100 - 240Vac)
9
Hardware Options
Without CT Input 0
With In = 1/5A CT Input 1
IEC 61850-9-2LE Sampled Analogue Values Ethernet board *
C
Hardware Options
Standard - None 1
Ethernet (100 Mbits/s) without IRIG-B
6
2nd Rear Port & InterMiCOM & IRIG-B (Modulated)
E
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Modulated IRIG-B G
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Un-modulated IRIG-B
H
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Modulated IRIG-B J
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Un-modulated IRIG-B
K
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Modulated IRIG-B
L
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Un-modulated IRIG-B M
Redundant Ethernet PRP/HSR, 2 fibre ports + Modulated IRIG-B
N
Redundant Ethernet PRP/HSR, 2 fibre ports + Unmodulated IRIG-B
P
Product Specific
16 Relays Outputs and 24 Status Inputs ** A
16 Relays Outputs, 4 High Break and 16 Status Inputs B
8 Relays Outputs, 4 High Break and 24 Status Inputs C
8 Relays Outputs, 8 High Break and 16 Status Inputs D
Protocol Options
K-Bus/Courier
IEC60870-5-103 (Via KITZ274)
Courier (K-Bus), IEC60870-5-103 via KITZ274 (Supplied as Courier. KITZ274 to be ordered)
Additional IEC61850
Mounting
Panel Mounting, with Harsh Environment Coating M
Language
Multilingual - English, French, German, Spanish 0
Multilingual - English, French, German, Russian 5
Software Issue
Unless specified the latest version will be delivered **
Customisation
Default 0
Customer specific A
Central Networks Version 5
Design Suffix
* Only available with '60' software
** 21 Relay Outputs and 24 Status Inputs For Suffix 'B' devices
Order Number
1
6
