Programmable Logic
(PL)
7-
6
MiCOM P74
1, P742, P743
PL
Link
Create a link between two logic symbols.
Opto Signal
Create an opto signal.
Input Signal
Create an input signal.
Output Signal
Create an output signal.
GOOSE In
Create an input signal to logic to receive a GOOSE message transmitted from another IED.
Used in IEC 61850 GOOSE applications only.
GOOSE Out
Create an output signal from logic to transmit a GOOSE message to another IED.
Used in IEC 61850 GOOSE applications only.
Control In
Create an input signal to logic that can be operated from an external command.
Function Key
Create a function key input signal.
Trigger Signal
Create a fault record trigger.
LED Signal
Create an LED input signal that repeats the status of tri-colour LED.
Contact Signal
Create a contact signal.
LED Conditioner
Create an LED conditioner.
Contact Conditioner
Create a contact conditioner.
Timer
Create a timer.
AND Gate
Create an AND Gate.
OR Gate
Create an OR Gate.
Programmable Gate
Create a programmable gate.
SR latch Gate
Create an
SR latch Gate.
