MiCOM P74
Relay
English Text Type Source Description
Isolator 6 discrepancy (Q6 Aux. (89b) = Q6 Aux.
(89a) for too long
Isolator 6 status position forced open (by default)
or closed
Validation of the virtual input 1 (signal correct).
Validation of the virtual input 64 (signal correct).
Input to Relay Output Conditioner
Input to Relay Output Conditioner
Output Relay 01 - All trips (FSL) but not retrip
Output Relay 02 - All trips (FSL) but not retrip
Output Relay 03 - All trips (FSL) but not retrip
(Commissioning)
Reset all indications (Led and relays latched in
PSL)
that includes the Led Alarm
All setting changes and most command/control
actions blocked for Rear Port 1.
All setting changes and most command/control
actions blocked for Rear Port 2 (when option
Analog to Digital Converter of the neutral current
saturated
Analog to Digital Converter of phase A current
saturated
Analog to Digital Converter of phase B current
saturated
Analog to Digital Converter of phase C current
saturated
Setting Group Selector X1 (low bit)
SG1 is active DDB 104=0 & DDB 105=0
SG2 is active DDB 104=1 & DDB 105=0
Setting Group Selector 1X (high bit)
SG3 is active DDB 104=0 & DDB 105=1
SG4 is active DDB 104=1 & DDB 105=1
Input to Auxiliary Timer 1
Input to Auxiliary Timer 16
Output from Auxiliary Timer 1
Output from Auxiliary Timer 16
Change on topology or configuration
Protection
Breaker fail trip order (50BF), general information
common to all PUs, the PU can be connected to an
Protection
Busbar trip order (87BB), general information
common to all PUs, the PU can be connected to an
Busbar trip order blocked by the CU
commissioning mode or Circuitry fault
Trip of Zone 1 (87BB, 50BF or manual)
Trip of Zone 8 (87BB, 50BF or manual)
Triggers User Alarm 1 message to be alarmed on
LCD display
Triggers User Alarm 7 message to be alarmed on
LCD display
Command
Allows binary signals that are mapped to virtual
inputs to interface into PSL
64
Command
Allows binary signals that are mapped to virtual
inputs to interface into PSL
