4.2.3.2 Trip (red) LED working? Yes / No
4.2.3.3 All 8 programmable LED’s working? Yes / No
4.2.4 Field supply voltage
Value measured between terminals
E7 and E9 (P742) or G7 and G9 (P743)
_______________V dc
Value measured between terminals
E8 and E10 (P742) or G8 and G10 (P743)
_______________V dc
4.2.5 Input opto-isolators:
Delete as appropriate (na = Not Applicable)
Opto input 2 working? Yes / No
Opto input 3 working? Yes / No
Opto input 4 working? Yes / No
Opto input 5 working? Yes / No
Opto input 6 working? Yes / No
Opto input 7 working? Yes / No
Opto input 8 working? Yes / No
For P742 Opto input 9 working? Yes / No / na
Opto input 10 working? Yes / No / na
Opto input 11 working? Yes / No / na
Opto input 12 working? Yes / No / na
Opto input 13 working? Yes / No / na
Opto input 14 working? Yes / No / na
Opto input 15 working? Yes / No / na
Opto input 16 working? Yes / No / na
For P743 Opto input 17 working? Yes / No / na
Opto input 18 working? Yes / No / na
Opto input 19 working? Yes / No / na
Opto input 20 working? Yes / No / na
Opto input 21 working? Yes / No / na
Opto input 22 working? Yes / No / na
Opto input 23 working? Yes / No / na
Opto input 24 working? Yes / No / na
