4.2.6 Output relays:
Complete or delete as appropriate
(na = Not Applicable, nm = Not Measured)
Relay 16 Working? Yes / No / na
Contact resistance (N/O)
__________Ω / nm
(N/C)
__________Ω / nm
Relay 17 Working? Yes / No / na
Contact resistance
__________Ω / nm
Relay 18 Working? Yes / No / na
Contact resistance
__________Ω / nm
Relay 19 Working? Yes / No / na
Contact resistance (N/O)
__________Ω / nm
(N/C)
__________Ω / nm
Relay 20 Working? Yes / No / na
Contact resistance (N/O)
__________Ω / nm
(N/C)
__________Ω / nm
4.2.7 Current Inputs
Complete or delete as appropriate
Displayed Current Primary/Secondary
Phase CT Ratio (na = not applicable) _______ / na
Input CT Applied value Displayed value
ΙA
______________A _______________A
ΙB
______________A _______________A
ΙC
______________A _______________A
ΙN
______________A _______________A
