GE P742

P74x/EN CM/Na7
Commissioning
(CM) 10-60
MiCOM P741, P742, P743
CM
0000 SYSTEM DATA
Alarm Status 2
Alarm Status 3
Access Level
Password Control
Password Level 1
Password Level 2
0800 DATE AND TIME
IRIG-B Sync

Disabled

Enabled
IRIG-B Status

Inactive

Active
Battery Status

Dead

Healthy
Battery Alarm

Disabled

Enabled
0900 CONFIGURATION
Setting Group

Select via Menu

Select via Optos
Setting Group 1

Disabled

Enabled
Setting Group 2

Disabled

Enabled
Setting Group 3

Disabled

Enabled
Setting Group 4

Disabled

Enabled
Dead Zone Prot

Invisible

Visible
BB Trip Confirm

Disabled

Enabled
Overcurrent Prot

Disabled

Enabled
Earth Fault Prot

Disabled

Enabled
CB Fail & I<

Disabled

Enabled
Input Labels

Invisible

Visible
Output Labels

Invisible

Visible
CT & VT Ratios

Invisible

Visible
Recorder Control

Invisible

Visible
Disturb Recorder

Invisible

Visible
Measure’t Setup

Invisible

Visible
Comms. Settings

Invisible

Visible
Commission Tests

Invisible

Visible
Setting Values

Primary

Secondary
Control Inputs

Invisible

Visible
Ctrl I/P Config.

Invisible

Visible
Ctrl I/P Labels

Invisible

Visible
Direct Access

Enabled

Disabled
 Hotkey only  CB Cntrl. only
InterMiCOM

Disabled

Enabled
Function Key

Invisible

Visible
