GE P742

Commissioning
P74x/EN CM/Na7
MiCOM P741, P742, P743
(CM) 10-67
CM
1500 INTERMICOM COMM (P743 only)
IM Input Status ______________
IM Output Status ______________
Source address ______________
Receive address ______________
Baud rate ______________
Ch Statistics

Invisible

Visible
Rx Direct count ______________
Rx Perm Count ______________
Rx Block Count ______________
Rx NewDataCount ______________
Rx ErroredCount ______________
Lost messages ______________
Elapsed ime ______________
Reset Statistics

Yes

No
Ch Diagnostics

Invisible

Visible
Data CD Status

OK

Fail

Absent

Unavailable
FrameSync Status

OK

Fail

Absent

Unavailable
Message Status

OK

Fail

Absent

Unavailable
Channel Status

OK

Fail

Absent

Unavailable
IM H/W Status

OK

Fail

Absent

Unavailable
Loopback mode

Disabled

internal

External
Test Pattern ______________
Loopback Status ______________
