IP8820/IP8830/IP8840
Installer Guide
D-3
Section
Field Name
Description
phone_802_priority Establishes the IEEE 802.1 priority for Ethernet frames at the
voice port, including signaling and voice packets, of the IP
Phone.
Valid values are 0 to 7.
Default is 5.
pc_vlan_id Assigns unique identifier of the VLAN for the PC port. A ‘0’
disables VLANS.
Valid values are 0 to 4094
Default is 0, disable.
phone_vlan_id Assigns unique identifier of the VLAN for the LAN (voice)
port. A ‘0’ disables VLANS.
Valid values are 0 to 4094
Default is 0, disable.
ssid Assigns the Service Set Identifier for the WiFi Network.
Valid value is up to 32 characters.
Default is unassigned.
security_mode Defines the security mode as WEP or WPA.
Valid values are 1-None, 2-WEP64, 3-WEP128, 4-WPA-PSK
or WPA2-PSK.
Default is 0, None.
wep_key1 Assigns the WEP Key value for Key 1.
Valid value is 10 hex digits for WEP64 or 26 digits for
WEP128.
Default is null.
wep_key2 Assigns the WEP Key value for Key 2.
Valid value is 10 hex digits for WEP64 or 26 digits for
WEP128.
Default is null.
wep_key3 Assigns the WEP Key value for Key 3.
Valid value is 10 hex digits for WEP64 or 26 digits for
WEP128.
Default is null.
wep_key4 Assigns the WEP Key value for Key 4.
Valid value is 10 hex digits for WEP64 or 26 digits for
WEP128.
Default is null.
wep_key_index Assigns the active WEP security Key when WEP security is
assigned.
Valid values are 1 to 4.
Default is unassigned.
WiFI
wpa_key Assigns the WPA security Key when WPA-PSK or WPA2-
PSK security mode is assigned.
Valid value is up to 64 hex digits or 8 to 63 ASCII characters.
Default is null
